matt black (BB), special decal, aluminum valve, capless design
| SIZE | PCD | OFFSET | DESIGN | BORE/CAP |
BB
|
MHB
|
MHS
|
MB
|
RR
|
WW
|
CHF
|
|
| sizes for japanese cars nut holes M12 | ||||||||||||
| 18x7.5 | 5x114.3 | 48 | S 37 | Ø 73 | 7.3 kg |
S
|
O
|
–
|
–
|
–
|
–
|
830.–
|
| 18x8.0 | 5x114.3 | 38,45,54 | S 37 | Ø 73 | 7.5 kg |
S
|
O
|
–
|
–
|
–
|
–
|
850.–
|
| 18x8.5 | 5x114.3 | 31,51 | S 37 | Ø 73 | 7.9 kg |
S
|
O
|
–
|
–
|
–
|
–
|
870.–
|
| 18x9.0 | 5x114.3 | 25,45 | M 53 | Ø 73 | 8.0 kg |
S
|
O
|
–
|
–
|
–
|
–
|
890.–
|
| 35,63 | S 37 | Ø 73 | 8.0 kg |
S
|
O
|
–
|
–
|
–
|
–
|
890.–
|
||
| 18x10.0 | 5x114.3 | 35 | M 53 | Ø 73 | 8.2 kg |
S
|
O
|
–
|
–
|
–
|
–
|
930.–
|
| 18x10.5 | 5x114.3 | 15,25 | E 72 | Ø 73 | 8.4 kg |
S
|
O
|
–
|
–
|
–
|
–
|
950.–
|
| 19x8.5 | 5x114.3 | 38,47 | S 37 | Ø 73 | 8.3 kg |
S
|
O
|
–
|
–
|
–
|
–
|
980.–
|
| 19x9.0 | 5x114.3 | 25 | M 56 | Ø 73 | 8.6 kg |
S
|
O
|
–
|
–
|
–
|
–
|
1'000.–
|
| 35 | S 37 | Ø 73 | 8.6 kg |
S
|
O
|
–
|
–
|
–
|
–
|
1'000.–
|
||
| 19x9.5 | 5x114.3 | 30,45 | M 56 | Ø 73 | 8.7 kg |
S
|
O
|
–
|
–
|
–
|
–
|
1'020.–
|
| 19x10.0 | 5x114.3 | 35 | M 56 | Ø 73 | 8.8 kg |
S
|
O
|
–
|
–
|
–
|
–
|
1'040.–
|
| 19x10.5 | 5x114.3 | 15,25 | E 72 | Ø 73 | 8.8 kg |
S
|
O
|
–
|
–
|
–
|
–
|
1'060.–
|
| 19x11.0 | 5x114.3 | 20 | E 72 | Ø 73 | 9.0 kg |
S
|
O
|
–
|
–
|
–
|
–
|
1'080.–
|
|
sizes for AUDI, SEAT, SKODA, VW or MERCEDES nut holes M14 cap rings for genuine ornament (option) hub rings AUDI, VW, SEAT, SKODA Ø 66.5 > 57.1 |
||||||||||||
| 18x8.0 | 5x112 | 48 | S 37 | Ø 66.5 / 63 | 7.5 kg |
S
|
O
|
–
|
–
|
–
|
–
|
850.–
|
| 18x8.5 | 5x112 | 45 | S 37 | Ø 66.5 / 63 | 7.9 kg |
S
|
O
|
–
|
–
|
–
|
–
|
870.–
|
| 19x8.0 | 5x112 | 48 | S 37 | Ø 66.5 / 63 | 8.1 kg |
S
|
O
|
–
|
–
|
–
|
–
|
960.–
|
| 19x8.5 | 5x112 | 45 | S 37 | Ø 66.5 / 63 | 8.3 kg |
S
|
O
|
–
|
–
|
–
|
–
|
980.–
|
| 19x9.0 | 5x112 | 48 | S 37 | Ø 66.5 / 63 | 8.6 kg |
S
|
O
|
–
|
–
|
–
|
–
|
1'000.–
|
| 19x9.5 | 5x112 | 29 | M 56 | Ø 66.5 / 63 | 8.7 kg |
–
|
O
|
–
|
–
|
–
|
–
|
1'020.–
|
| 50 | M 56 | Ø 66.5 / 63 | 8.7 kg |
S
|
O
|
–
|
–
|
–
|
–
|
1'020.–
|
||
|
sizes for BMW nut holes M14 cap ring for genuine ornament (option) |
||||||||||||
| 18x8.0 | 5x120 | 45 | S 37 | Ø 72.5 / 73 | 7.5 kg |
S
|
O
|
–
|
–
|
–
|
–
|
850.–
|
| 18x8.5 | 5x120 | 35 | S 37 | Ø 72.5 / 73 | 7.9 kg |
S
|
O
|
–
|
–
|
–
|
–
|
870.–
|
| 18x9.0 | 5x120 | 50 | M 53 | Ø 72.5 / 73 | 8.0 kg |
S
|
O
|
–
|
–
|
–
|
–
|
890.–
|
| 18x9.5 | 5x120 | 25 | E 72 | Ø 72.5 / 73 | 8.1 kg |
S
|
O
|
–
|
–
|
–
|
–
|
910.–
|
| 35 | M 53 | Ø 72.5 / 73 | 8.1 kg |
S
|
O
|
–
|
–
|
–
|
–
|
910.–
|
||
| 19x8.0 | 5x120 | 45 | S 37 | Ø 72.5 / 73 | 8.1 kg |
S
|
O
|
–
|
–
|
–
|
–
|
960.–
|
| 19x8.5 | 5x120 | 35 | S 37 | Ø 72.5 / 73 | 8.3 kg |
S
|
O
|
–
|
–
|
–
|
–
|
980.–
|
| 19x9.0 | 5x120 | 20,50 | M 56 | Ø 72.5 / 73 | 8.6 kg |
S
|
O
|
–
|
–
|
–
|
–
|
1'000.–
|
| 19x9.5 | 5x120 | 25 | E 72 | Ø 72.5 / 73 | 8.7 kg |
S
|
O
|
–
|
–
|
–
|
–
|
1'020.–
|
| 35,50 | M 56 | Ø 72.5 / 73 | 8.7 kg |
S
|
O
|
–
|
–
|
–
|
–
|
1'020.–
|
||
| 19x10.0 | 5x120 | 22 | E 72 | Ø 72.5 / 73 | 8.8 kg |
S
|
O
|
–
|
–
|
–
|
–
|
1'040.–
|
| 19x11.0 | 5x120 | 30 | E 72 | Ø 72.5 / 73 | 9.0 kg |
S
|
O
|
–
|
–
|
–
|
–
|
1'080.–
|
|
sizes for MINI nut holes M14 cap ring for genuine ornament (option), hub rings Ø 63 > 56.1 |
||||||||||||
| 18x7.5 | 4x100 | 42 | S 37 | Ø 63 | 7.3 kg |
S
|
O
|
–
|
–
|
–
|
S
|
830.–
|
| 39 | M 53 | Ø 63 | 7.3 kg |
S
|
O
|
–
|
–
|
–
|
S
|
830.–
|
||
|
sizes for PORSCHE nut holes M14 spherical design – special ADVAN hub cap, genuine PORSCHE cap and bolts can be used |
||||||||||||
| 18x8.5 | 5x130 | 40,52 | S 37 | Ø 71.6 / 78 | 8.2 kg |
S
|
–
|
O
|
–
|
–
|
–
|
910.–
|
| 18x9.5 | 5x130 | 40 | M 53 | Ø 71.6 / 78 | 8.4 kg |
S
|
–
|
O
|
–
|
–
|
–
|
940.–
|
| 18x11.0 | 5x130 | 60 | M 53 | Ø 71.6 / 78 | 8.7 kg |
S
|
–
|
O
|
–
|
–
|
–
|
980.–
|
| 19x8.5 | 5x130 | 40 | S 37 | Ø 71.6 / 78 | 8.6 kg |
S
|
–
|
O
|
–
|
–
|
–
|
1'010.–
|
| 52 | S 37 | Ø 71.6 / 78 | 8.6 kg |
S
|
–
|
O
|
O
|
O
|
–
|
1'010.–
|
||
| 19x10.0 | 5x130 | 40 | M 56 | Ø 71.6 / 78 | 9.0 kg |
S
|
–
|
O
|
O
|
O
|
–
|
1'070.–
|
| 19x11.0 | 5x130 | 40 | E 72 | Ø 71.6 / 78 | 9.3 kg |
S
|
–
|
O
|
O
|
–
|
–
|
1'110.–
|
| 60 | M 56 | Ø 71.6 / 78 | 9.3 kg |
S
|
–
|
O
|
O
|
O
|
–
|
1'110.–
|
||
| 19x12.0 | 5x130 | 50,65 | E 72 | Ø 71.6 / 78 | 9.4 kg |
S
|
–
|
O
|
–
|
O
|
–
|
1'150.–
|
| S Serie, O Option, – not available; rim depth in mm: S standard, M medium, E extra | ||||||||||||
front and rear axles can be combined with two versions of spoke shapes (and widths)
| options | |
| machining & racing hyper black (MHB) |
+ 60.–
|
| machining & racing hyper silver (MHS) |
+ 60.–
|
| machining & racing black (MB) |
+ 40.–
|
| racing red (RR) |
+ 40.–
|
| racing white (WW) |
no extra cost
|
| hub cap Ø 63 or Ø 73 ADVAN Racing |
+ 50.–
|
| cap ring for genuine ornament |
+ 50.–
|
